How to choose a pet feed production line?
Leave a message
How to choose a pet feed production line?
Key points for equipment selection
Capacity matching: Small production lines are suitable for family farms, and large fully automatic lines are suitable for large-scale feed factories.
Raw material adaptability: It must be compatible with crude fiber raw materials such as soybean meal, fish meal, grains and straw, and support dry/wet process switching.
Automation level: Equipment equipped with a PLC control system is preferred.
| Size for whole line | According to land size and layout. |
| Pellet size | 1-12mm |
| Capacity | 5-10t/h |
| Workers requirments | 4-5people |
| Shipment requirments | 5*40ft container |
| Range of application | large commerical Aquatic/ pets feed factory |
| Process flow | 1.bucket elevator 2.raw materials cleaning system-3.silos for crusher 4.crusher 5.Raw material automatic distribution weighing system 6.mixing system 7.second crushing system 8.Raw material automatic distribution weighing system 9.second mixing system 10.extruder 11.drying system 12.screen system -13.seasoning machine 14.cooling system 15.packing system |
The typical extruded aquafeed production line process includes:
Crushing of raw materials:
Remove rope ends, metal impurities and other foreign objects to ensure the safety of the raw materials. Then crush the raw materials.
Mixing and conditioning:
The moisture and temperature of the material are adjusted through the temperature control system.
Granulation equipment:
Fish feed extruder is the core process of the entire production line. It adopts wet or dry process, supports floating/sinking feed switching, and improves starch gelatinization.
Post-processing and packaging:
After the particles are cooled, they are sprayed with functional additives, sieved to remove broken particles, and finally packaged and stored.
Our advantages:
1. One sinking fish feed production line can produce two kinds of feed, saving fixed asset investment and improving equipment utilization; feed intake.
2. The process of first proportioning and then crushing is adopted, which has a simple process flow, compact structure, low investment and energy saving;
3. The crushing system adopts a process combining crushing and grading, so that the particles that reach the required particle size after crushing do not need to be crushed repeatedly, which increases the output of the crusher and does not waste electricity.
About MIKIM
The whole process is automated and energy-saving and environmentally friendly, supporting customized production to meet the high-efficiency needs of large farms. When purchasing, you must first choose a reliable fish feed pellet equipment manufacturer. Only when the manufacturer is reliable can the equipment be guaranteed.
MIKIM can provide customers with a one-stop, full set of professional floating fish feed production solutions to solve the problems of customers, especially pure investment customers, who have difficulty in equipment technology and do not understand it, making the project's needs and positioning clearer, and also making the customer's fish feed equipment selection range more concentrated, reducing energy, financial and other cost consumption.
For more information on process design, equipment layout, plant construction plan, single machine equipment quotation, turnkey quotation, etc., please feel free to contact us.
