MIKIM MACHINERY
MIKIM 0.04-6T/H fish Feed Pellet Machine For Sale
DGP series floating fish feed extruder machine
- Capacity: 40-2000KG/H
- Raw materials: Fish meal, soybean meal, rapeseed meal, corn gluten meal, Fish oil, premix, etc.
- Pellet diameter: 1-9mm
- Type: Dry-Type Fish Feed Extruder
- Motor: Electric/Diesel (optional)
- Customizable machine: Yes
- Screw: single screw
- Applicable animals: chickens, ducks, geese, pigs and other poultry and domestic animals; cattle, sheep, horses, rabbits and other ruminants; fish, shrimp and other aquatic animals；dog, cat and other pets.
- WhatsApp:+86 136 7305 0773
- Email: market@mikimz.com
Our Dry Type fish feed pellet extruder machine price typically ranges from $1,500 to $8,500, depending on the configuration, capacity, and level of automation.
24 hours to reply to technical inquiries
LX series floating fish food extruder
- Capacity: 40-800KG/H
- Raw materials: Fish meal, soybean meal, barley, yeast powder, wheat bran, starch, vitamin mixture, etc.
- Pellet diameter: 1-9mm
- Cutting Slide Rail: Included
- Type: Dry Type fish feed pellet extruder machine
- Materials: Carbon steel/Stainless steel (customizable)
- Screw: single screw
- Applicable animals: chickens, ducks, geese, pigs and other poultry and domestic animals; cattle, sheep, horses, rabbits and other ruminants; fish, shrimp and other aquatic animals；dog, cat and other pets.
- WhatsApp:+86 136 7305 0773
- Email: market@mikimz.com
Our LX series floating fish feed pellet making machine price typically ranges from $1,500 to $8,500, depending on the configuration, capacity, and level of automation.
Single-screw floating fish feed machine
- Capacity: 180-4000KG/H
- Raw materials: Fish meal, soybean meal, rapeseed meal, corn gluten meal, Fish oil, premix, etc.（Limited to standard recipes)
- Applicable animals: Tilapia, grass carp, catfish, shrimp and other aquatic animals；dog, cat and other pets.
- Pellet diameter: 1-9 mm (customizable)
- Type: Wet Type fish feed pellet extruder machine
- Conditioner: Included
- Screw: single screw
- Crane Boom: Included
- Fat/Oil Content：Low to Medium (Up to 10-12%)
Our single screw floating fish feed making machine price typically ranges from $9,500 to $55,500, depending on the configuration, capacity, and level of automation.
Twin-screw floating fish feed machine
- Capacity: 250-6000KG/H
- Raw materials: Fish meal, soybean meal,rice bran, wheat bran, lecithin, premix, etc. (Can process diverse & sticky materials)
- Pellet diameter: 0.5-9mm（Customizable）
- Type: Wet Type floating fish feed pellet mill
- Conditioner: Yes
- Screw: Twin screw
- Crane Boom: Included
- Fat/Oil Content：High (Up to 17-22% or more)
- Self-cleaning Capability：Excellent (Strong self-cleaning action)
- Product Uniformity: Superior (Extremely stable shape/size)
- Application：Floating Fish Feed，Sinking Shrimp Feed，Micro-particle Feed，Pet Food，Livestock & Poultry Feed
Our Twin screw floating fish feed pellet making machine price typically ranges from $10,500 to $6,500, depending on the configuration, capacity, and level of automation.
Technical Features Of Floating Fish Feed Machine
- Our floating fish feed making machine has the following technical features:
- PLC+touch screen control system, easy to operate and simple;
- The main engine adopts frequency conversion control, and the screw speed can be adjusted, which is suitable for different formulas (sinking material, semi-floating material, floating material)
- The fully meshed, zero-clearance twin-screw mechanism can effectively control the shear force and ensure that the curing time of all materials in the extruding cavity is consistent with the particle expansion coefficient;
- The appearance of the particles is neat, the water resistance is good, and the diameter of the mold is φ0.6mm-20mm; the vertical gear reducer drives the arch breaking device;
- The bearing in the transmission box adopts FAG or SKF bearing to ensure long-term stable operation;
- Effectively distribute the reasonable shear force in different areas of the extrusion cavity, and effectively increase the output under the premise of ensuring high quality;
- The new fully wear-resistant alloy (38CrMoAi) screw and the inner sleeve of the bimetal expansion cavity can effectively reduce the wear and tear and ensure the long-term stable operation of the equipment under the condition of high production capacity and high quality;
- The cutting part adopts a movable cutter seat, and the blade is made of spring steel, which fits well with the template. The cutter is driven by a frequency conversion motor, which can control the length of the product;
- The turbulent discharge device discharges the material to make the extruded puffed material more beautiful;
- Use a kind of general-purpose floating fish feed extruder machine to produce floating feed and sinkable feed according to the demands. The auxiliary bulk density control system can be selected for the fish feed production of high bulk density extruded pellets.
- Customers just need to change a few fish feed extruder machine parts to produce exruded soybean, extruded corn and sheeted suckling pig feed different character feed raw materials at the same time, reducing the cost for customers.
We utilize the profile of screw and liner, direct steam injection into the extrusion barrel, and heating/cooling jacket to generate the most suitable cooking of the raw material.
In floating fish feed, other aqua feed and pet food production, the addition of a pre-conditioning system can help increase the pre-cooking and hydrating process to manufacture premium feed with high water stability.
Benefits of floating fish feed extruder machine
- Increase capacity for sink feed production more than 15%
- Lower moisture in outlet 2-3%, lower the need of drying
- Smoother pellet surface
- Eliminate the need of oil to control density
- Slow and fast sinking made possible
- Customizable for different types of extruder
With the wide application and continuous development of extrusion technology, the types of fish feed floating pellet making machine are increasing day by day, and their classification methods are also diverse.
According to the strength of the shear force, it can be divided into high shear force, medium shear force, and low shear force extrusion extruder; according to the heating mode, it can be divided into self-heating and external heating or called dry fish stock feed extruder machine and wet extruder for fish feed. Get Latest Price
How to produce floating fish feed —— Complete floating fish feed production process
- Raw material intake system consisting of tip hopper, mechanical conveyors, and elevators into storage bins. Raw material such as soybean meal, corn, fish meal, and other grain or powder is sieved to remove any impurity and metals.
- Pre-grind systems are a size reduction process for raw materials that contain large particulates or grains by hammer mills. Pre-grinding material is conveyed to storage bins.
- Batching and dosing system weighing hoppers to proportionally weigh dry ingredients by batches based on every formulation.
- The first mixing system is used for dry material mixing to stabilize the following process.
- Second grinding is the second grinding process that grinds the formulation into finer powder with fineness up to 80 mesh 95% pass. This step becomes optional when making big extrudates with sizes of 2.5 mm and up.
- Second mixing system: Other sources like pre-mix, liquid, oil, and fat are now added and mixed with raw material. Too much fat added here will affect the floatability, so a post-extrusion oil coater will be used to account for the total fat content required.
- Extrusion cooking with pre-conditioning: The floating fish feed mixer feeds down through a feed hopper into the feed screws which continuously feed the ingredients into a differential diameter conditioner (DDC). Water, steam, and/or oil are added in DDC, the retention time inside DDC is controlled by shaft speed. Two types of extrusion technology can be chosen: single screw floating fish pellet extruder or twin screw floating fish feed machine.
- Drying system: The floating fish dryer machine will lower the moisture content of the extrudate from 20% to 28% in the dryer inlet down to 10-12%. This drying is needed to lower the water activity and achieve shelf-stable moisture for the products.
- Oil coating system is needed to increase the nutritional value and palatability of the feed. Depending on the fat content that needs to be added, a drum coater or A vacuum coater can be chosen.
- Cooling system lowers the temperature of the hot pellets to +3°C of room temperature by utilizing ambient air.
- Screening system: All pellets will go through a vibration sieve to remove any irregular pellets or impurities before bagging.
- Bagging and sealing system: Weighing cell and bagging machines bag pellets with chosen quantity ex: 20 Kg. or 25 Kg. per bag and seal the bags for storage. Finished products can also be loaded by trucks or in container bags.
Why Choose Us
Advanced Equipment
A machine, tool or instrument designed with advanced technology and functionality to perform highly specific tasks with greater precision, efficiency and reliability.
High Quality
Our products are manufactured or executed to a very high standard, using the finest materials and manufacturing processes.
Professional Team
Our professional team collaborates and communicates effectively with each other, and is dedicated to delivering high quality results. We are capable of handling complex challenges and projects that require our specialized expertise and experience.
Customized Services
We understand that each customer has unique manufacturing needs. That’s why we offer customization options to cater to your specific requirements.
One-stop Solution
At our manufacturing facilities, we provide a complete package that includes everything required to get you started, including training, installation and support.
24h Online Service
We try and respond to all concerns within 24 hours and our teams are always at your disposal in case of any emergencies.
Company Profile
FAQ
Q: What is a fish feed extruder machine?
Q: What is the working principle of a fish feed extruder machine?
Q: What are the different types of fish feed extruder machines?
Q: What are the advantages of using a fish feed extruder machine?
Q: What factors should be considered when selecting a fish feed extruder machine?
Q: What is the difference between a single-screw and a twin-screw fish feed extruder?
Q: What is the role of the conditioner in a fish feed extruder machine?
Q: What is the importance of pellet quality in fish feed production?
Q: Can a fish feed extruder machine be used for custom feed formulations?
Q: What safety measures should be taken when operating a fish feed extruder machine?
Q: Can a fish feed extruder machine be used for high-protein feed production?
Q: Can a fish feed extruder machine be used for low-density feed production?
Q: What is the typical lifespan of a fish feed extruder machine?
Q: Can a fish feed extruder machine be customized for specific fish species?
Q: What is the role of the cutter in a fish feed extruder machine?
Q: Can a fish feed extruder machine handle different types of materials?
Q: What maintenance is required for a fish feed extruder machine?
Q: Can a fish feed extruder machine be used for medicated feed production?
Q: Can a fish feed extruder machine be used for multi-species feed production?
Q: Can a fish feed extruder machine be used for high-fat feed production?
We're professional fish feed extruder machine manufacturers and suppliers in China, specialized in providing high quality customized service. Please feel free to wholesale high-grade fish feed extruder machine made in China here from our factory.
