1-2 T/H Pet Food Fish Feed Production Line With Automatic Weighing And Dividing System





The Aquaculture Automatic Pellet Feed Production Line streamlines the manufacturing process through a sequential industrial workflow: Hammer Mill [→] Auger Feeder [→] Ribbon Blender [→]Wet-type Single-Screw floating fish food extruder machine [→] Pneumatic Conveyor [→] Multi-layer Belt Dryer [→] Cooling Conveyor [→] Rotary Coating Drum [→] Automatic Bagging Machine, ensuring high-efficiency output for professional aquafeed and pet food processing.



1–2 T/H Wet-type Single-Screw floating fish food pellet making production line test for Iraqi customer





I am interested in this line



This Fully automatic puffing feed production line is engineered for the high-throughput production of specialized aquafeed (floating, sinking, and slow-sinking fish feed) and premium pet food kibble for dogs and cats.









ITEM	MACHINE NAME	PICTURE	MACHINE PARAMETER	Remark
1	Vertical hammer crusher		Model：600 Power:22kw Capacity: 3-4t/h Weight: 420kg Dimensions: 1*1*1.1m	Achieve the exact grinding fineness needed for high-quality feed. Our [animal feed crusher machine】 delivers consistent 60-80 mesh output, maximizing the surface area for efficient downstream extrusion
2	Bucket Screw elevator		Length: 3m Power: 2.2kW Weight: 150kg Dimensions: 3.2 x 0.5 x 0.5 m	Automate your production flow. This heavy-duty [Screw Conveyor] ensures precise material dosing into the mixer while maintaining a dust-free factory environment.
3	U-shaped horizontal mixer		Output: 1000 kg/batch Power: 7.5 kW Dimensions: 3.2*1.1*2.2 m Weight: 1000kg	Critical for high-fat recipes. Our [fish feed mixer machine] guarantees high mixing homogeneity (CV < 5%), ensuring that every oil droplet and micro-ingredient is perfectly distributed.
4	Screw Conveyor		Length: 5m Power: 2.2kW Weight: 200kg Dimensions: 5.2*0.5*0.5 m	Automate your production flow. This heavy-duty [Screw Conveyor] ensures precise material dosing into the mixer while maintaining a dust-free factory environment.
5	Wet-type single screw floating fish feed pellet extruder machine		Capacity: 1.2-1.5T/H Main drive motor: 90 kW Feeding system motor: 2.2 kW Cutting system motor: 3 kW Conditioning system motor: 11 kW Barrel configuration: 6 sections Requires a steam boiler or steam generator.	Raw materials: Fish meal, soybean meal, rapeseed meal, corn gluten meal, Fish oil, premix, etc. Applicable animals: Tilapia, grass carp, catfish, shrimp and other aquatic animals;dog, cat and other pets. Pellet diameter: 1-9 mm (customizable) Type: Wet Type fish feed pellet extruder machine Screw: single screw Conditioner: Included Crane Boom: Included Steam boiler: Not included Fat/Oil Content：Up to 10-12%   The core of your production. Our [Wet-type single screw floating fish feed pellet extruder machine] features an independent pre-conditioner to stabilize starch gelatinization, even in formulations with 10%+ fat content.
6	Pneumatic conveyor		Fan motor power: 2.2 kW	Gentle handling for fragile pellets. Use our [Pneumatic Conveying System] to transfer hot extrudates instantly to the dryer without physical damage or sticking
7	Animal Feed Pellet Drying Machine		Dryer: 5-tier structure / 5 m Heating power: 45 kW Fan motor power: 2.2 kW × 4 units Conveyor motor power: 3 kW Dimensions: 5.5*1*2 m Weight: 1.5t Material: 304 stainless steel	Precision moisture control is non-negotiable. Our [Economic Multi Layer Aquatic Floating Fish Feed Dryer Machine] reduces moisture to a stable 8-10%, preventing mold and extending shelf life without over-drying
8	Cooling conveyor machine		Length: 5m Dimensions: 5.2*0.6*0.5 m Weight: 200kg	Stabilize your product before bagging. Our [Cooling Conveyor] brings pellet temperatures down to ambient levels, preventing condensation and preserving pellet hardness.
9	Automatic Octagonal Drum Seasoning Machine		Power: 1.5kw Weight: 200kg Processing time: 5-8 min/barrel Dimensions: 4.5*0.8*1.6m Material: 304 stainless steel	Boost palatability and energy density. The [Stainless steel drum Seasoning Machine] provides uniform surface application of oils and nutrients, ideal for high-fat premium pet foods
10	Automatic Bag Filling Packing Machine		Packaging System Packaging Capacity: 200-300 bags/hour Weighing Accuracy: Static: ±0.1% Dynamic: ±0.2% Power Supply:380 V, 50 Hz ±2%, 4.5 kW Compressed Air Supply:0.6-0.8 MPa Compressed Air Consumption:0.2 Nm³/min Quantity:1 unit	Conveyor Function:Conveying filled bags to the next processing stage. Technical Parameters: Conveyor Length:3000 mm Power Supply:380 V, 50 Hz, 0.37 kW Quantity:1 unit   Bag Sewing System Sewing Machine Model:35-6A / 35-2C Technical Parameters: Maximum Sewing Speed:1,600 stitches/min Stitch Length:6.5-11 mm Stitch Type:Double-thread chain stitch Thread Specification:21S/5 and 21S/3 polyester thread Needle Type:80800, 280-250# Power Supply:380 V, 50 Hz, 0.37 kW Quantity:1 unit   Finish your line with precision. This [Automatic Bag Filling Packing Machine] offers ±0.2% gravimetric accuracy, ensuring every bag is retail-ready and perfectly sealed.











Feature / Category	Dry Type single screw floating fish feed pellet extruder machine	Wet-type single screw floating fish feed pellet machine	Impact on Production
Internal Fat/Oil Tolerance	Low (max 3% - 5%)	Higher (up to 10% - 12%)	High oil acts as a lubricant; too much oil in dry machines causes "slippage," stopping the cooking process.
Core Mechanism	Mechanical friction & shear generate 100% of the heat.	Combines steam injection (thermal) with mechanical shear.	Wet process allows for more precise temperature control.
Pre-Conditioning	None. Raw materials enter the barrel dry.	High-intensity steam conditioning (60-90 seconds).	Conditioning hydrates and pre-cooks the mash for better quality.
Moisture Content	Low: 12% - 18%.	High: 25% - 32%.	Higher moisture in wet extrusion is key to superior starch cooking.
Starch Gelatinization	60% - 80% (Partial).	90% - 95%+ (Comprehensive).	Higher gelatinization = better digestibility and water stability.
Output Capacity	Lower (limited by motor torque).	Higher (up to 30-50% more for the same motor).	Steam softens the material, allowing for higher throughput.
Wear & Tear (Parts)	High. Intense friction accelerates screw and barrel wear.	Lower. Steam acts as a plasticizer/lubricant, extending part life.	Wet extrusion reduces the frequency of costly maintenance downtime.
Energy Profile	High Specific Mechanical Energy (SME) from electricity.	Lower SME; balanced with thermal energy (steam).	Shifts the energy load to the boiler, which is often more cost-effective.
Water Stability	Average (15-30 minutes).	Excellent (several hours to 24h+).	Vital for aquafeed to prevent nutrient leaching in water.
Initial Investment	Lower (No boiler or steam piping required).	Higher (Requires boiler, conditioner, and piping).	Dry is better for start-ups; Wet is for professional commercial lines.
Pellet Density	Limited control over floating/sinking.	Precise control over buoyancy and expansion.	Necessary for specialized fish feed (floating/sinking/slow-sinking).



☆Click to compare the maintenance requirements and spare parts service life of Dry Type single screw floating fish feed pellet extruder machineand Wet-type single screw floating fish food pellet maker machines.



[Get a Free Technical Evaluation from Our Engineers]

(Not sure about Dry vs. Wet? We'll analyze your recipe for free.)







The floating fish meal making production line can produce feed pellets with diameters ranging from 1 to 9 mm.



1. Specialized Shapes

We offer custom mold (die) engineering to produce shapes that enhance brand identity and palatability:

• Pet Food: Hearts, Bones, Triangles, Stars, Rings (Donuts), Crosses, and standard Round/Pill shapes.
• Aquafeed: Perfect spheres for uniform sinking rates and cylindrical pellets for optimized feeding.





2. Product Categories & Types

• Floating Aquafeed: High-expansion pellets that stay buoyant for 24h+, ideal for Tilapia, Catfish, and Carp.
• Sinking & Slow-Sinking Feed: Precise density control for Shrimp, Salmon, and Trout.
• Professional Pet Kibble: High-protein, high-fat formulations for puppies, adult cats, and active working dogs.









Q1: How long does it take to switch between different pellet shapes?

Answer: Switching shapes requires a change of the extrusion die. Our Quick-Change Die System allows for a complete transition in approximately 15 to 30 minutes. This minimizes downtime and allows for small-batch production of multiple product lines within a single shift.



Q2: Can a single screw floating fish feed pellet extruder machine produce 1.0mm micro pellets reliably?

Answer: Yes, but it requires high-precision grinding of raw materials (at least 80-100 mesh) and a specific high-pressure die plate. For micro-pellets, we recommend the Wet-process system to ensure the starch is fully gelatinized, which prevents the small pellets from crumbling in water.



Q3: What is the maximum percentage of fresh meat or oil I can add?

Answer: In our Wet-type single screw floating fish feed pellet making machine, you can effectively process recipes with up to 20-30% fresh meat slurry and 8-12% internal fat. For higher lipid requirements, our lines are designed to integrate with [External Vacuum or Drum Coaters] to reach total fat levels of 25%+.



Q4: How do you guarantee the pellets won't fall apart in water?

Answer: Stability is determined by the Pellet Durability Index (PDI). By achieving 90%+ starch gelatinization through our steam conditioning process, the starch acts as a natural binder. This creates a durable matrix that maintains structural integrity in water for up to 24 hours, depending on the formulation.



Q5: Why is a cooling conveyor necessary before packaging?

Answer: Pellets exit the dryer at high temperatures. If bagged immediately, the residual heat causes "moisture migration," leading to condensation inside the bag and subsequent mold growth. Our [Cooling Conveyor] reduces the core temperature to within 3-5°C of ambient air, ensuring a shelf-stable product.
