Livestock Feed Pellet Production Line for Poultry, Cattle, and Animal Feed Manufacturing
Leave a message
Product introduction
Livestock feed pellet production lines can be used to make feed pellets for livestock at different stages. Especially suitable for customers who are preparing to build a feed mill. Feed pellets can be sold or used in your farm.MIKIM has many years of experience with sales and designing of feed mills with capacities ranging from 1t/h to 100t/h all over the world - from small farm use licestock feed plants to large industrial livestock feed mill plants producing feed for pig, rabbit, cattle, sheep, etc. No matter where in the world and no matter which requirements the client may have to the new livestock feed production line, MIKIM has a matching solution.
Types of livestock feed pellet production lines
According to the types of livestock, livestock feed pellet production lines can be divided into cattle feed pellet production lines, sheep feed pellet production lines, pig feed pellet production lines, rabbit feed pellet production lines, horse feed pellet production lines, deer feed pellet production lines, donkey feed pellet production line, etc. Among them, the first three are the most common livestock feed production lines.
Product parameters
| Scale | Total Power | Site Requirements | Installation Cycle | livestock Feed Mill Cost(USD) |
|---|---|---|---|---|
| 1-2T/H | 47-75KW | 300-500m² | 7-15 Days | 10000-50000 |
| 3-4T/H | 53-165KW | 300-700m² | 15-20 Days | 5,0000-12,0000 |
| 5-7T/H | 68-259KW | 400-800m² | 20-40Days | 7,0000-25,0000 |
| 8-10T/H | 125-410KW | 800-2000m² | 45-60 Days | 150,000-300,000 |
| 12-20T/H | 358-620KW | 1500-3000m² | 60-90 Days | 250,000-580,000 |
| 25-40T/H | 545-870KW | 2000-4000m² | 90-120Days | 45,0000-850,000 |
| 50-60T/H | 710-1120KW | 3000-5000m² | 100-140 Days | 900,000-1,400,000 |
| 60-80T/H | 815-1370KW | 5000-8000m² | 130-160 Days | 1,450,000-1,800,000 |
| 80-100T/H | 1230-1700KW | 8000-20000m² | 160 -190Days | 2,000,000-2,800,000 |
Livestock Feed Pellet Production Line Process Design
01 Cleaing & dosing & weighing section
MIKIM Machinery offers a complete program of livestock feed equipment for cleaning, dosing and weighing of raw materials and other components. The program includes among other things weighing bins, micro proportioning plant, mineral hoppers, sceen cleaners etc., with capacities of up to 3 tons per batch.
02 Grinding section
MIKIM Machinery livestock feed hammer mill has adjustable milling degree, has a low energy consumption, minimal dust emission and an extremely low noise level.
03 Mixing
MIKIM mixer is a reliable, gentle feed mixer with a high mixing accuracy due to the auger with large diameter and low number of revolutions. Where high capacity and mixing accuracy are required we offer the horizontal mixer that can be equipped with pre-bin and post-bin. The horizontal livestock feed mixer is tested to a mixing accuracy of 1:100,000, which is sufficient for commercial feed production.
MIKIM single and twin shaft paddle mixer is perffect for mixing of compound feed and feed ingredients. Mixing time and accuracy is verified by CE that lasts.
04 Conveying section
MIKIM Machinery offers a complete program of equipment for mechanical transportation, including flex augers, tubular augers, trough augers, bucket elevators, and chain conveyors. We offer a wide range of accessories for all types, and great reliability of operation.
05 Pelleting section
If pelleted feed is required, MIKIM can supply customized livestock feed pelleting plants as an integrated part of the livestock feed factory. We have great experience in supplying and installing livestock feed pellet production plants throughout the world in sizes ranging from 1 to 100 t/h.
06 Silo system
MIKIM Machinery also projects and supplies complete solutions for grain storage facilities including high quality fully galvanized steel silos, flat storage plants, continuous flow grain dryers, intake pits, grain cleaners and conveying equipment, Capacities from a few hundred up to many thousands tonnes.
FAQ
1. What is the price of Poultry pelletizing production line?
The price ranges from approximately US$17,500.00 - 59,900.00.
2. Do you provide maintenance services for your customers?
Yes, we offer comprehensive after-sales maintenance services to our customers.
For more information on process flow design, equipment layout, factory construction plans, individual equipment pricing, or turnkey project proposals, please feel free to contact us!!!
