Animal Feed Pelletizer

dog pellet machine can produce pellet feed that animals need, and the quality is good

Send Inquiry

feed pellet machine

Description

Dog food pellet making machine

Dog food pellet making machine Die plate aperture

According to our many years of customer accumulated experience, the breeding of different types of animals, the choice of pellet mill mill grinding hole is also different, we provide a variety of pellet mill specifications mill aperture, for your choice. (The length of the pellet material, the customer is free to adjust)
1. 2.0mm mill is for breeding: parrots, parakeets, finches, and other pet birds.
2. 2.5mm mill is for breeding: young rabbits, young chickens, young ducks, young geese, young pigeons, young birds, young peacocks, young aquatic fish and other small animals.
3. 3-4 millimeter mill is breeding: rabbits, chickens, ducks, geese, pigeons, birds, peacocks, aquatic fish, etc.
4. 5-6 millimeter mill is breeding: pig, cow, sheep, dog, pig, horse.
5. If you have special requirements, please note the aperture requirements of the pellet mill, we will install and debug the shipment according to your requirements.

Dog pellet machine

chicken food pellet machine

Model	Main Power(kw)	Capacity(kg)	Rotating speed	Dimensions(mm)	Weight + Motor(kg)
120	3	20--40	320	1020×530×1120	30+36
125	3	40--50	320	1040×550×1140	32+36
150	4	75--125	320	1280×600×1250	48+44
180	7.5	125--175	320	1400×750×1300	72+66
210	11	200--250	320	1500×850×1400	89+100
260	15	350--500	380	1980×800×1600	180+124
300	18.5	500--800	380	2080×900×1750	260+153
360	30	800--1200	400	2000×860×1700	340+215
400	37	1200--1500	400	2200×1200×1950	400+264

How to choose Machine for making chicken feeds

1. Voltage: If your house has both single-phase/two-phase (220V) and three-phase (380V) power supply, it is recommended that customers pick three-phase power supply (380V), because three-phase motors are relatively more powerful. The voltage is more stable.
2. If your family only has single-phase/two-phase (220V) voltage, please rest assured that the 120 feed pellet mill for home use with single-phase/two-phase (220V) is equipped with a pure copper wire double-value capacitor 3kw motor. This is the standard power of our equipment, which can fully meet the normal production, processing and use.

Animal feed pelletizer

About Pellet maker for animal feed

Start the feed pellet machine, pour the mixture into the hopper, the main shaft and flat die drive the pressure roller to rotate under the friction. The material is pasted at high temperature between the pressure roller and the mold plate, the protein coagulates and denatures, and is discharged from the mold holes under the extrusion of the pressure roller, and the made pellets are adjustable through the cut-outs. Caution, if the powder in the hopper stagnant, remember not to shovel by hand, so as not to hurt your hands. Wood chips or emergency stop should be used. :Speed selection, due to the nature of the raw materials used by the user is different, you can choose the speed according to the bonding degree of the material and the dryness and humidity. Wet material should be slow, the specific situation depends on the actual operation. The correct use of feed pelletizer can not only ensure the normal operation of the pelletizer equipment, but also ensure the production efficiency of the equipment, and most importantly, ensure the safety of the operator.
