Extruder Machines



The effect of puffing on the main ingredients of feed:
1. It improves the pasting degree of starch and generates modified starch with high water absorption and bonding function. Because of its high water absorption, it allows us to add more liquid ingredients (such as oil, molasses, etc.) to the product, and at the same time, because it has a much stronger bonding function than ordinary starch, the amount of starch added in the puffing production process can be greatly reduced. This provides more leeway for the choice of other raw materials, the formula can choose a variety of cheaper raw materials to replace those expensive raw materials, can be a large number of cost reductions without affecting the quality of the product.
2,Because the protein is combined with starch matrix, so it is not easy to lose when feeding, only when the digestive enzymes in the animal body decompose the starch to release the protein, which improves the protein potency. The puffing process also denatures the proteins, blunting many anti-nutritional factors, while changing the tertiary structure of the proteins, shortening the hydrolysis time of the proteins in the intestinal tract. For ruminants, expansion to generate rumen non-degradable protein, that is, over the rumen protein, can avoid ammonia poisoning of animals, improve the utilization of protein.
3, puffing treatment of raw material molecules in the encapsulated fat release, improve the caloric value of fat, puffing will also be fat and starch or protein together to form a complex product of lipoproteins or lipopolysaccharides, reducing the content of free fatty acids, and at the same time passivation of the lipase enzyme, inhibit degradation of fats and oils to reduce the rancidity of fat and oil components of the product storage and transportation process. In addition, puffing treatment also reduces the bacterial, mold and fungal content of raw materials, improves the hygienic quality of feed, reduces the addition of various pharmaceutical ingredients; improves palatability; improves the efficiency of low-quality raw materials and reduces feed costs.







1. Advanced diced structure. Adopting knife shaft locating spring combined cutting form to cut the same length particle.

2. The screw adopts abrasion-resisting high temperature alloy steel, with characters of abrasion-resistance and long service.

3. There is unique pressurized die device inside to ensure the feed's production and quality.

4. Reasonable mainshaft bearing combination to ensure puffing machine's security and duration.

5. Main motor adopts high quality three-phase motor to ensure strong power.

6. The particle puffing feed produced by this machine can float in water 12 hours without dispersing. It is pollution-free and easy to be digested by fish.

7. The feed after produced through high temperature can kill escherichia coli, salmonella and other harmful bacterial, ensure the feed's hygiene.

8. It can save feed 8%-15%.







1. Enlarge and widen the feed inlet, wear-resistant and durable

2. Pure copper motor, strong power, low noise

3. Thick and flexible belt, silent transmission, strong adhesion

4. Variety of feed shape grinding tools are available

5. Independent power control box, easy to operate and safe

6. Separate variable speed cutting device, feed pellet length can be adjusted

7. Spiral discharge opening, uniform discharge

8. Wear-resistant slicing, easy to disassemble





Model	Power(kw)	Capacity(kg/h)	Feed power(kw)	Cutting power(kw)	Weight(kg)	Dimension(mm)
AKP-40	7.5kw	40-50	0.4	0.4	310	1300*1100*1200
AKP-50	11kw	80-100	0.4	0.4	330	1350*1100*1200
AKP-60	15kw	120-150	0.4	0.4	360	1350*1100*1200
AKP-70	18.5kw	180-200	0.4	0.4	410	1500*1360*1250
AKP-80	22kw	200-240	0.4	0.4	460	1500*1450*1250
AKP-90	30kw	400-500	1.1	1.5	800	1650*1450*1300
AKP-135	55kw	500-700	1.1	1.5	1200	1800*1550*1500







The main equipment is "screw extruder". The material is fed into the extruder, and the screw propels the material to form an axial flow. At the same time, due to mechanical friction between the screw and the material, the material and the barrel as well as the material inside, the material is strongly extruded, stirred, sheared, and the result is that the material is further refined and homogenized. With the gradual increase in pressure, the temperature rises accordingly, in the high temperature, high pressure, high shear conditions, the physical properties of the material changes from powder to paste, starch paste, protein denaturation, fibrous part of the degradation, refinement, pathogenic bacteria are killed, health indicators to improve the inactivation of toxic ingredients. When the paste material from the mold hole spray out the moment, under the action of a strong pressure difference, the material is puffed, water loss, cooling, puffed product structure is loose, porous, crispy, and have a better palatability and flavor.











The key electronic components, pneumatic and hydraulic systems of MIKIM Machinery are all made of well-known brands to ensure the high quality and reliability of agricultural and feed machinery. Through the unremitting efforts of all staff, MIKIM Machinery has won the recognition and trust of our customers for its excellent performance, advanced technology and good reputation.
Our machines are widely used in various fields in China and exported to Southeast Asia, Europe, Africa, South America, Middle East countries and other regions. European technology, perfect performance. Mikim -Machine is your reliable machinery supplier.
We have attractive prices and are looking for overseas agents, welcome to contact us for more information, cooperating with us will save a lot of cost for your company.You are welcome to consult us at any time.
