Fish And Shrimp Feed Expander

Fish feed extruder is the best choice for aquaculture farms.

Send Inquiry

Description

Products Description

Main parts
Screw: It is the main part of the extruder. The parameters that indicate the screw structure include diameter, pitch, root diameter, helix angle and blade cross-sectional structure. The aspect ratio of the extrusion component and the gap between the screw and the inner wall of the extruder chamber also have a great influence on the performance of the extruder.
Discharging die: It is the last checkpoint for the product to pass through the extruder. It has a great influence on the shape, texture, density, appearance, characteristics of the product and the production volume of the extruder.

Product Parameters

Model	MK65	MK70	MK85	MK95
Installed capacity	76kw	95kw	178kw	256kw
Power	54kw	66kw	125kw	195kw
Output	140-160kg/h	240-260kg/h	500kg/h	1000-1200kg/h
Dimension	1722.5m	2222.5m	2623.5m	422.84m

The working principle of the feed extruder is to process feed using high temperature and high pressure. After entering the extruder, the feed is first heated and moistened by the screw conveyor, and then enters the high-pressure extrusion chamber. Under the high-pressure, high-temperature and high-speed environment, the feed suddenly relaxes. The rapid diffusion of high-pressure air causes the feed to form a high-temperature, high-pressure and high-speed environment within 0.1 seconds. Protein, starch, fat and other ingredients quickly denature and expand, achieving sterilization, insecticide, detoxification, improving the internal structure of food, and improving the palatability and nutritional value of feed.

Feed extruder is a device that heats and expands feed to make high-nutritional feed that various animals like. It can convert low-quality feed into high-quality, high-taste and high-nutrition feed. In agricultural production, the application of feed extruder has been widely promoted and used.
